The Ansmann TC130PD Travel Charger is a compact and versatile USB-C charger designed for use at home or while travelling. It features a built-in fold-out US plug and includes interchangeable UK and EU plug adapters, making it suitable for use in a wide range of countries.

The USB-C port delivers up to 30W of power and supports numerous fast-charging protocols, including PD3.0, PPS, Quick Charge, AFC, FCP, SCP, and MTK-PE+2.0, ensuring compatibility with a wide variety of devices.

With a universal 110-240V AC input, built-in protection against short circuits, overvoltage, and overcurrent, an IP20 rating, and CE certification, it provides safe and reliable charging wherever you are. Supplied in white box packaging.

Features

• Economical and intelligent USB device charger
• Built-in fold-out US plug with changeable 3 pin UK and 2 pin EU plug options
• Single USB-C port with up to 30W power delivery
• Input: 110-240V AC at 50/60Hz for worldwide use
• Output: 5-20V at 3A maximum
• Compatible with PD3.0, PPS, QC4+, QC3.0, QC2.2, AFC, FCP, SCP, MTK-PE+2.0, DCP, Apple 2.4A and Samsung 5V-2A protocols
• Multi-protection against short circuit, over voltage and over current
• IP20 ingress protection rating and CE marked

Specifications

Input Voltage	110V-240V AC
Max. Input current	1.5A
AC frequency	50/60Hz
Port	USB-C
Output voltage	5V - 20V DC
Max. output current	3A
Maximum power	30W
Functions	Over voltage protection, over current protection, short circuit protection
Charging protocol	USB
USB-ports	1
Average operational efficiency	84.67%
Efficiency at low load	80.53%
Colour	Black
Storage temperature	-20°C --- 70°C
Operating temperature	-20°C --- 25°C
Ingress protection marking	IP20
Dimensions	Body 59x56x29mm UK Plug 31x50x44mm EU Plug 42x35x30mm

Resources

• Product information sheet
• EAN: 4013674226276
• Product number: Ansmann 1001-0194

Package Contents

• 1x Ansmann 30W Travel Charger TC130PD
